- OD3 Green-Yellow Laser – available in a wide range of output powers, this is the ultimate classic pen sized green-yellow laser.
- Convenient and Portable – the OD3 555nm green-yellow output and is portable enough to be used anywhere.
- Improved Laser Casing – the casing has been re-designed for improved shock absorption, making this yellow laser pointer stand the test of time.
|
| Model： |
OD3 Green-Yellow Laser Pointer |
| Brand： |
Shadowlasers |
| Wave Length： |
555nm |
| Dimension： |
φ29.5*120mm |
| Max Output Power： |
20MW
|
| Laser Classification： |
Class IIIB |
| Focus Mode： |
Fixed Focus |
| Switch Mode： |
Constant On/Off Button |
| Surface Treatment： |
Hard Anodizing Black |
| Body Material： |
Aircraft Grade Aluminum |
| Laser Net Weight： |
110g |
| Expected Lifetime： |
> 8000 Hours |
| Usage Method： |
30 Seconds on & 60 Seconds off， Continuous use should NOT exceed 2 Minutes! |
| Battery Type：： |
1*18350 Li Battery |
| Battery Direction： |
The Battery "+" Is Toward Inside of The Laser Pointer |
| Working Time： |
> 1 Hour |
| Working Voltage： |
DC = 3.0-4.2V |
| Starting Voltage： |
DC = 2.5V |
| Working Current： |
3.7V@400mA |
| Circuit Control： |
4.2V Step-Down Constant Current With Reverse Connection Protection |
| Laser Range： |
500-2000 Meters |
| Max Brightness： |
350Lm |
| Circuit Control： |
APC |
| Flare Forms： |
Plaque-Forming - Circle |
| Beam Style： |
Continuous Line |
| Spot Size： |
5 Meters Place < φ8~φ12mm |
| Preheat Time： |
< 3 Seconds |
| Warranty： |
1 Year Manufacturer's Warranty |
|
PACKING LIST
1 * Green-Yellow Laser Pointer
1 * 18350 Rechargeable Li Battery
1 * US Charger (Adapter To Fit Your Country)
|
